Scientific Image Gallery
Welcome to our Scientific Image Gallery. Here you can find real-life examples of cell images, mostly (but not only) from peripheral blood films, that illustrate typical morphologic characteristics pointing to specific conditions or disorders. This constitutes their diagnostic value.
Click on an image to enlarge it and display a short description.
Cytoplasmic fragments split off a blast in a case of acute lymphoblastic leukaemia (ALL). In certain automated haematology analysers, such fragments might possibly suggest a wrongly high concentration of platelets.
<p>Cytoplasmic fragments split off a blast in a case of acute lymphoblastic leukaemia (ALL). In certain automated haematology analysers, such fragments might possibly suggest a wrongly high concentration of platelets.</p>
Cytoplasmic protrusions of a lymphocyte in normal blood. (Although such protrusions are frequently found with infections, contrary to activated lymphocytes they are of no diagnostic importance.)
<p>Cytoplasmic protrusions of a lymphocyte in normal blood. (Although such protrusions are frequently found with infections, contrary to activated lymphocytes they are of no diagnostic importance.)</p>
Granulocytes showing storage-related degradation (for example, vacuolisation) can be seen in EDTA blood samples from healthy individuals after 1–2 days (here after 48 hours). In samples from severely ill patients this can occur already after several hours.
<p>Granulocytes showing storage-related degradation (for example, vacuolisation) can be seen in EDTA blood samples from healthy individuals after 1–2 days (here after 48 hours). In samples from severely ill patients this can occur already after several hours.</p>
Bone marrow cytology (May-Grünwald-Giemsa stain) of a patient with B-CLL: Dense infiltration of the bone marrow by the B-CLL. Megakaryocyte count and morphology are normal.
<p>Bone marrow cytology (May-Grünwald-Giemsa stain) of a patient with B-CLL: Dense infiltration of the bone marrow by the B-CLL. Megakaryocyte count and morphology are normal.</p>
Diagnosis of AML in the bone marrow: Characteristic are bundles of Auer rods (->) and many atypical promyelocytes.
<p>Diagnosis of AML in the bone marrow: Characteristic are bundles of Auer rods (->) and many atypical promyelocytes.</p>
During the preparation of a large number of blood films for EQA purposes, the blood drop on the slide had already started to dry prior to smearing, so that, when the blood film was made, many white blood cells were pulled towards the edge, resulting in disturbed cell distribution.
<p>During the preparation of a large number of blood films for EQA purposes, the blood drop on the slide had already started to dry prior to smearing, so that, when the blood film was made, many white blood cells were pulled towards the edge, resulting in disturbed cell distribution.</p>
Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation.
<p>Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation.</p>
Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation.
<p>Doehle bodies were named after the German pathologist Karl Gottfried Paul Döhle (1855-1928). They are defined as light blue-grey oval inclusions with a diameter of 1 to 3 µm located in the peripheral cytoplasm of mature and immature neutrophils. The structures are seemingly derived from the rough endoplasmic reticulum and hence contain RNA. They are often present in conjunction with toxic granulation. </p> <p> </p>
At low magnification, a drop of saliva is easily detected. When enlarged considerably, it might cause confusion.
<p>At low magnification, a drop of saliva is easily detected. When enlarged considerably, it might cause confusion.</p>
