Scientific Image Gallery
Welcome to our Scientific Image Gallery. Here you can find real-life examples of cell images, mostly (but not only) from peripheral blood films, that illustrate typical morphologic characteristics pointing to specific conditions or disorders. This constitutes their diagnostic value.
Click on an image to enlarge it and display a short description.
The peripheral blood (May-Grünwald-Giemsa stain) of this patient shows only isolated neutropenia (900/μL) with morphologically normal red blood cells and normal red blood cell and platelet counts. Aplastic anaemia is not present. A lymphocyte can be seen in the middle.
<p>The peripheral blood (May-Grünwald-Giemsa stain) of this patient shows only isolated neutropenia (900/μL) with morphologically normal red blood cells and normal red blood cell and platelet counts. Aplastic anaemia is not present. A lymphocyte can be seen in the middle.</p>
Peripheral blood (May-Grünwald-Giemsa stain) of a patient with B-CLL. The few platelets are mostly large (->) (= platelet anisocytosis). Here a secondary immune thrombocytopenia (ITP) was evoked by immunoglobulin-producing lymphoma cells. The immunoglobulins react with proteins on the platelet surface, leading to an elimination of these platelets from the peripheral blood.
<p>Peripheral blood (May-Grünwald-Giemsa stain) of a patient with B-CLL. The few platelets are mostly large (->) (= platelet anisocytosis). Here a secondary immune thrombocytopenia (ITP) was evoked by immunoglobulin-producing lymphoma cells. The immunoglobulins react with proteins on the platelet surface, leading to an elimination of these platelets from the peripheral blood.</p>
The peripheral blood (May-Grünwald-Giemsa stain) of a patient with breast cancer and bone metastases demonstrates a leucoerythroblastic picture. There are left-shifted granulopoiesis (e.g. here a myelocyte (M)), erythroblasts (E) and distinct thrombocytopenia.
<p>The peripheral blood (May-Grünwald-Giemsa stain) of a patient with breast cancer and bone metastases demonstrates a leucoerythroblastic picture. There are left-shifted granulopoiesis (e.g. here a myelocyte (M)), erythroblasts (E) and distinct thrombocytopenia.</p>
Peripheral blood (May-Grünwald-Giemsa stain) of a 27-year old patient with chronic myelogenous leukaemia (CML). Normal red blood cells, marked thrombocytosis (2,750,000/µL), increased basophilic granulocytes (->) and a normal white blood cell count are observed. In this case no JAK2 mutation could be detected; instead the patient was tested positive for the BCR-ABL fusion gene.
<p>Peripheral blood (May-Grünwald-Giemsa stain) of a 27-year old patient with chronic myelogenous leukaemia (CML). Normal red blood cells, marked thrombocytosis (2,750,000/µL), increased basophilic granulocytes (->) and a normal white blood cell count are observed. In this case no JAK2 mutation could be detected; instead the patient was tested positive for the BCR-ABL fusion gene.</p>
The peripheral blood (May-Grünwald-Giemsa stain) of a 27-year old patient with hearing loss showed a massive leukocytosis (680,000/µL) and a marked left shift with a distinct fraction of blast cells. Several eosinophilic cells are clearly visible. Platelets are abundant, although not visible in this part of the blood film. The BCR-ABL fusion gene was detected by FISH analysis of the peripheral blood and secured the diagnosis of CML. Because of the threat of permanent loss of hearing chemotherapy was started within hours after venepuncture (without waiting for the results from bone marrow cytology).
<p>The peripheral blood (May-Grünwald-Giemsa stain) of a 27-year old patient with hearing loss showed a massive leukocytosis (680,000/µL) and a marked left shift with a distinct fraction of blast cells. Several eosinophilic cells are clearly visible. Platelets are abundant, although not visible in this part of the blood film. The BCR-ABL fusion gene was detected by FISH analysis of the peripheral blood and secured the diagnosis of CML. Because of the threat of permanent loss of hearing chemotherapy was started within hours after venepuncture (without waiting for the results from bone marrow cytology).</p>
The peripheral blood (May-Grünwald-Giemsa stain) of a patient shows as an incidental finding leukocytosis with left shift up to myelocytes, basophilia and mild thrombocytosis. CML was suspected and later confirmed by cytogenetic demonstration of the Ph1.
<p>The peripheral blood (May-Grünwald-Giemsa stain) of a patient shows as an incidental finding leukocytosis with left shift up to myelocytes, basophilia and mild thrombocytosis. CML was suspected and later confirmed by cytogenetic demonstration of the Ph1.</p>
Peripheral blood (May-Grünwald-Giemsa stain) of a patient with ET showing an isolated thrombocytosis. A JAK2 mutation was detected by molecular biological techniques. The BCR-ABL fusion gene was not found.
<p>Peripheral blood (May-Grünwald-Giemsa stain) of a patient with ET showing an isolated thrombocytosis. A JAK2 mutation was detected by molecular biological techniques. The BCR-ABL fusion gene was not found.</p>
Peripheral blood (May-Grünwald-Giemsa stain) of a patient with MDS: on the left a pseudo-Pelger-Huet cell, on the right a dysplastic metamyelocyte. Anaemia and atypical platelets are also present. After peripheral blood and bone marrow analysis the diagnosis of refractory anaemia with excess of blasts (RAEB-1) was made.
<p>Peripheral blood (May-Grünwald-Giemsa stain) of a patient with MDS: on the left a pseudo-Pelger-Huet cell, on the right a dysplastic metamyelocyte. Anaemia and atypical platelets are also present. After peripheral blood and bone marrow analysis the diagnosis of refractory anaemia with excess of blasts (RAEB-1) was made.</p>
Peripheral blood (May-Grünwald-Giemsa stain) showing a typical B-CLL with an elevated lymphocyte count, normal granulocyte and platelet counts and normal red blood cells.
<p>Peripheral blood (May-Grünwald-Giemsa stain) showing a typical B-CLL with an elevated lymphocyte count, normal granulocyte and platelet counts and normal red blood cells.</p>
